恭喜您购买了60baat 蓝牙速度和踏频器
本产品需求：
1.60beat BLUE自行车（速度和节奏传感器）
2. iPhone 4S，iPhone 5或兼容的智能设备
3.与60beat兼容的应用程序
BLUE（兼容应用程序的列表保留在
www.60beat.com）
基本步骤:(使用Cyclemeter App）
1.在您的iPhone上下载Cyclemeter应用程序
（或其他60beat BLUE支持的App）
2.在自行车上安装自行车传感器（看安装
详细说明）
3.在iOS设备上打开蓝牙
4.打开循环仪应用程序
5.Pair 60beat蓝色自行车与设备
6.开始锻炼
传感器在自行车上的安装
1.通过蓝色传感器插入尼龙扎带
2.将传感器放在后链撑上
靠近踏板。放置海绵
传感器和链条支架之间。
直到完全拧紧领带
对齐。
3.将曲柄磁铁放在曲柄上
（磁铁很坚固
不需要额外的夹具。
将轮磁铁放在轮辐上）。
将曲柄磁体与顶部对齐
左传感器部分。
对准轮磁体
速度传感器。
4.Pair 60Beat蓝色自行车与设备。
BULE没有开/关
开关。设备启动时
磁铁通过传感器。所以一旦
安装，旋转踏板或轮
启动传感器。
5.开始锻炼
Congratulations on your purchase of the 60baat BLUE
Bike.
THIS PRODUCT REQUIRES:
1.The 60beat BLUE Bike (speed and cadence sensor)2. An iPhone 4S, iPhone 5 or compatible smart device
3.An application that is compatible with the 60beat
BLUE ( a list of compatible Apps is maintained at
BASIC STEPS:( Using Cyclemeter App )1. Download the Cyclemeter App on your iPhone
( or other 60beat BLUE supported App )
2. Install Bike sensor on bike ( look at installation
instructions for details )
3. Turn on Bluetooth on your iOS device
4. Open the Cyclemeter App
5. Pair 60beat BLUE Bike with device
6. Start your workout
INSTALLATION OF SENSOR ON BIKE
near the pedal. Place sponge
between sensor and chain stay.
Do not tighten ties until fully
aligned.
( magnet is strong and does
not need additional fixture.
Place wheel magnet on spoke) .
Align crank magnet with top
left portion of sensor.
Align wheel magnet with
speed sensor.
The BULE does not have an on/off
switch. The device starts when the
magnets pass by the sensor. So once
installed, rotate pedal or wheel to
initiate sensor.
PAIRING with Cyclemeter (could vary depending on
App used)
1.“More” on bottom right
2.Sensors
3.Add Sensor
4.Bike Speed Cadence
5.The sensor is turned off until the magnet
passes by the sensor. Turn the bike wheel,
once the magnet passes by the sensor, the
smart device can now detect the sensor.
6.Press OK and the smart device should detect.
Not working
Bluetooth is not turned on(IMPORTANT: You
will not see Bike sensor listed in the Bluetooth
Setting area).
Magnet not close enough to sensor, adjust so
magnets are closer to sensor.
PACKAGE CONTAINS
1.Combo Sensor
2.Wheel Magnet
3.Crank Magnet
4.Sponge
5.Nylon Ties
CHARACTERISTICS
Transmission Distance 5Meters
Transmission frequency 2.4G
Battery Life (using 1 hour per day) 1-2 years
BATTERY REPALCEMENT
1.Using a coin, open the battery cover
by turning counter clockwise to the
open position
2.Remove the old battery
3.Insert the battery (CR2032 ) with the
positive (+) facing the cover
4.Press the cover back into the connector
5.Use the coin to turn the cover clockwise
to “Close”. When changing the battery,
make sure seal ring is in place to maintain
water resistance.
LIMITED WARRANTY
The limited warranties provided by 60beat apply only to
new product purchased for your own use, and not for resale
or export outside of the United States. 60beat warrants
that the hardware and any accessories will be free of
defects in workmanship and materials, under normal use,
for 1(one ) year from the original purchase date. The
warrants do not apply to any software product which are
designed to work in conjunction with the 60beat products.
The warrants do not apply to damages that result from
misuse, accident, environmental stress or improper use.
60beat standard warranty details are available at
DISCLAIMER
60beat or its’ owner shall not be liable for any damages,
losses, costs or expenses, direct, indirect or incidental,
consequential or special, arising out of, or related to the
use of this material or the products described herein.
DISPOSAL OF DEVICE:
Do not throw the device in the garbage.Please dispose
of the device in an appropriate way, treating it as electronic
waste. For details, please consult your local recycling service.
FCC: RULES PART 15
The enclosed hardware device complies with part 15 of
the FCC Rules. Operation is subject to the following two
conditions (1) The device may not cause harmful interference
and (2) it must accept any interference received, including
interference that may cause undesired operation.
CE:
The CE mark shows compliance of this product with the
European Union EMC Directive 93/42/EEC.
5. Start your workout
4. Pair 60Beat BLUE Bike with device.
3. Place crank magnet on crank
1. Put Nylon ties through the BLUE sensor
2. Place sensor on rear chain stay
